Max rated lifting capacity
55t
Max lifting moment
203.5 tm
Max lifting moment with fixed jib
112 tm
Boom length
13-52 m
Fixed jib length
6.1-15.25 m
Longest (boom+fixed jib)
43+15.25 m
Boom luffing angle
30°-80°
Fixed jib offset angle
10°, 30°
Speeds
Rope speed of main/auxiliary winches
0-130 m/min
Rope speed of boom/jib luffing winches
0-80 m/min
Single rope pull
7 t
Rope diameter
Φ22 mm
Travelling speed
0-1.3 km/h
Slewing speed
0-1.9 rpm
Gradeability
40%
Engine
Model
Cummins QSB5.9-C210
Rated power
154/2200 kW/rpm
Rated torque
820 Nm / 1400 rpm
Emissions
Tier Ⅲ
Transportation
Crane weight
50 t
Counterweight
16 t
Max transport weight of single part
32.3 t (with chassis, boom base)
Maxtransport dimensions
12200×3000×3300 mm (with chassis, boom base)
Average ground pressure
0.065 MPa
